ZustandGebraucht
Lagernummer0401528
Komplette Produktionsanlage für
Sägewerk
3-Schicht Parkettherstellung
Leimholz-, Türen- und Fensterproduktion
Fragen zu dieser Maschine?
Complete system
SAWMILL,
PARQUET-,
PANELS-,
DOORS-WINDOWS FACTORY

EQUIPMENT LIST SAWMILL
1. Vertical saw mill Esterer A.G.
Type: HDN 600
Year: 1991
Opening 700mm
Working dimensions
- length: 2500- 5000 mm
- width: 100- 700 mm
Power system
- transverse conveyor with chains - 2 pieces
- longitudinal conveyor with belt with metal detector
- longitudinal conveyor chain and scraper
- loading barrow with hydraulic motor
Evacuation system
- longitudinal conveyor with rollers
- transverse conveyor with chains
2. Multiple splitting circular Esterer A.G.
Type: DK90-O
Year: 1996
Working dimensions:
- length: 1000- 5000 mm
- width: 50- 700 mm
- thickness: 30-130 mm
Circular webs Ø: 250- 500 mm
Power system: transverse conveyor with chains
Evacuation system:
- longitudinal conveyor with rollers
- longitudinal conveyor with belt
3. Splitting and edging circular Esterer A.G.
Type: DK90 B/E
Year: 1996
Working dimensions:
- length: 1000- 5000 mm
- width: 50- 700 mm
- thickness: 30-80 mm
Circular webs Ø: 250- 350mm
Power system: transverse conveyor with chains
Evacuation system:
- longitudinal conveyor with rollers
- transverse conveyor with chains
4. Automatic installation for cutting and picking strips Dimter Weining Gruppe.
Type: Opticut 304 R
Year: 2003
Working dimensions:
- length: 1000- 5000 mm
- width: 50- 130 mm
- thickness: 25-60 mm
Circular webs Ø: 500 mm
Power system:
- transverse conveyor with chains - 2 pieces
- fluorescence chalk marks reader
Evacuation system with belts with 5 pneumatic sorting stations
5. Circular cutting pendulum Paul. 6 pieces
Type: 17 AP
Year: 1996
Working dimensions:
- length: 250- 5000 mm
- width: 20- 150 mm
- thickness: 20-80 mm
Circular web Ø: 500mm
Installed power -3,7 kw
Power system: transverse conveyor with belt
6. Circular cutting pendulum Paul. 2 pieces
Type 17 AP
Year: 1999
Working dimensions:
- length: 250- 5000 mm
- width: 20- 150 mm
- thickness: 20-80 mm
Circular web Ø: 500mm
Installed power -3,7 kw
Power system: transverse conveyor with belt
7. Circular cutting pendulum Paul. 1 piece
Type: 17 AP
Year: 1979
Working dimensions:
- length: 250- 5000 mm
- width: 20- 150 mm
- thickness: 20-80 mm
Circular web Ø: 500mm
Installed power - 3,7 kw
Power system - transverse conveyor with belt


TOOL DRESSING SAWMILL HOUSE
1. Sharpening blades machine sawmill Vollmer
Type: GA 250 M
Year: 1996
2. Saw setting machine sawmill Vollmer
Type: GSA
Year: 1996
3. Flat knives sharpening machine Vollmer
Year: 1996
HEATING STATION
1. Hot water boiler Vincke
Type: IV WW 4000
Year: 1996
Pressure: 3 bar
Max. temperature: 110˚C
Capacity: 10550 l
2. Hot water boiler Vincke
Type: IV WW 2500
Year: 1996
Pressure: 3 bar
Max. temperature 110˚C
Capacity: 8000 l
3. Hot water boiler KARA
Type: KDT 220
Year: 2001
DRYERS
1. Hot air dryer Brunner-Hildebrand: 7 pieces
Type: HTR 100
Year: 1996
Installed power: 29 kw
Carrier temperature (hot water): 90˚C
Capacitate: 60 cm
2. Hot air dryer Brunner-Hildebrand: 1 piece
Type: HTR 100
Year: 1998
Installed power: 62 kw
Carrier temperature (hot water): 90˚C
Capacity: 120 cm


EQUIPMENT LIST PARQUET SAWMILL


I LINE TOP LAYER SCHROEDER
1. Strips charger superior layer Schroeder
Year: 1996

Working dimensions:
- length: 250- 800 mm
-width: 50- 100 mm
-thickness: 25-50 mm
Installed power -1,5 kw
Advance system - chain with spurs
2. Dressing machine Schroeder
Type: WH/ PAKE 70
Year: 1996
No. of working trees: 3 pieces
Working dimensions:
- length: 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of tool holder head: 230mm
Installed power -54,2 kw
Advanced system - chain with spurs
Power system - conveyor with belt
Evacuation system - conveyor with belt
3. Joiner Schroeder
Type: PAKE 70
Year: 2000
No. of working trees: 4 pieces
Working dimensions
- length : 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of tool holder head: 230mm
Installed power - 29,1kw
Advanced system - chain with spurs
Evacuation system - conveyor with belt
4. Cutting ends machine at 90˚ Schroeder
Type: PAKE 4S
Year: 1996
No. of working trees: 4 pieces (circular blades)
Working dimensions:
- length: 250- 800 mm
- width: 50- 100 mm
- thickness: 25-50 mm
Ø of circular blades: 250mm
Installed power -12,7kw
Advance system - chain with spurs 2 pieces
Power system - pneumatic storage box
Evacuation system - conveyor with belt
5. Lamellate machine Schroeder
Type: S2
Year: 1996
No. of working trees: 2 pieces (port pins circular blades)
Working dimensions:
- length: 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of circular blades: 280mm
Installed power - 50,9kw
Advance system - cu role
Evacuation system - conveyor with belt
6. Equipment line for mats forming for top layer on the edge with glue stick
HYFRA (2 lines)
Type: VWK 21/1 S
Year: 1996
Hot press
Dimensions top layer mat:
- length : 2400 mm
- width: 180 mm
3 rows upper layer disks
Ø of circular blades: 280mm
Installed power -1,57kw
Advance system - belt with clow
Power system : conveyor with 3 bands and disks storage boxes
Evacuation system - portal elevator
7. Equipment line for mats forming for top layer fuse wire bonding
Disks gluing system - fuse wire on one side (zig-zag)
Power system: conveyor with 3 bands and disks storage boxes
Evacuation system - vacuum suction elevator
III LINE BOTTOM LAYER
1. Cutting circular with automatic programming for dimensions PAUL.
Type: Paul 11 E
Year: 1996
Working dimensions:
- length: 500- 5000 mm
- width: 50- 130 mm
- thickness: 25-60 mm
Installed power -10,3kw
Ø of circular blades: 500 mm
Power system - longitudinal conveyor with band
Evacuation system - conveyor with band
2. Joiner Schroeder
Type: PAKE 70
Year: 1996
No. of working trees: 4 pieces
Working dimensions:
- length: 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of tool holder head: 230mm
Installed power -29,1kw
Advance system - chain with spurs
Evacuation system - conveyor with band
3. Lamellate machine Schroeder
Type: S2
Year: 1996
No. of working trees: 2 pieces (port pins circular blades)
Working dimensions:
- length: 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of circular blades: 320mm
Installed power -50,9kw
Advance system - with rollers
Evacuation system - conveyor with rollers
II LINE MIDDLE LAYER
1. Cutting circular Kallfass
Type: RA 3000-8L
Year: 1996
Working dimensions:
- length: 500- 3000 mm
- width: 50- 250 mm
- thickness: 25-60 mm
Installed power -56 kw
Ø of circular blades: 500 mm (8 pieces)
Alimentation system - transversal conveyor with chain with catcher (14 pieces)
Evacuation system conveyor with rollers
2. Dressing machine
Type: Kupfermuhle
Year: 1962
No. of working trees: 1 piece
Working dimensions
- length: 400- 2400 mm
- width: 50- 700 mm
- thickness: 25-50 mm
Ø of tool holder head: 200mm
Installed power -20 kw
Advance system - with rollers
3. Lamellate machine Raimann
Type: KS 310
Year: 1996
No. of working trees: 1 piece (port sleeve circular blades)
Working dimensions:
- length: 400- 2400 mm
- width: 50- 300 mm
- thickness: 25-50 mm
Ø of circular blades: 380mm
Installed power -81,5kw
Advance system - metal track with spurs
Evacuation system - conveyor with band
PRESS LINE
1. Equipment line for mats forming for middle layer fuse wire bonding Linear
Product
Type: 077472
Year: 1996
Working dimensions:
- length: 2400 mm
- width: 480 mm
- thickness: 8mm
Length forming circular
Installed power -41,8kw
Advance system - conveyor with two chains (2 pieces)
2. Machine for applying glue on both sides with rolls Burkle
Type: CAK 600
Year: 1996
Drums dimensions - length: 600 mm
Length forming circular
Installed power -1,1kw
Evacuation system - lift portal
3. Equipment line for forming the parquet plate 2400x480 mm
Conveyor width 500mm
Cold press
4. Press Burkle
Type: HPB 1126/140-5x2
Year: 1996
No. of working trees: 1 piece (port sleeve circular blades)
Loading press capacity 5 floors x 2 levels
- length: max 2500 mm
- width: max 1100 mm
Heat carrier -hot water
Installed power -38,5kw
Loading press system - elevator on 5 levels, conveyors with band
Evacuation system - elevator on 5 levels, conveyors with rollers
5. Heat carrier pump system for press Heiza Mattil
Type: H-HWST
Year: 1996
6. Formatting circular parquet panels
Longitudinal and transversal circular
Year: 1996
Power system: conveyor with rollers
Advance system: Conveyor with band
Evacuation system: conveyor with rollers
Tools: circular blades 2 pieces
Grinding lower layer
Grinding upper layer
Varnish application
UV drying
Spatula application
UV drying
Varnish application
UV drying
Film polishing
2 Varnish layers application
UV drying

FINISHING LINE
1. Lower layer grinding machine Tagliabuie
Type: TAG 1 INF
Year: 1996
Grinding unit with low drum 1 piece
Band width 1330 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 55 kw
2. Upper layer grinding machine Tagliabuie
Type: TAG 112
Year: 1996
Grinding unit with up drum 2 pieces
Grinding unit with segmented probe 1 piece
Band width 1330 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 118 kw
3. Varnish application machine Burkle 4 pieces (drum)
Type: SAL 1
Year: 1996
Maximum width 1300 mm
Advance system: conveyor with bars
4. Spatula application machine Burkle 1 piece (drum)
Type: CASC 1300
Year: 1996
Maximum width 1300 mm
Advance system: conveyor with bars
5. Drying varnish system UV IST (4 units)
Type: 2xHL-140-1-N-DL
Lamp type: UV CK 1400
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
6. Polishing top layer machine Tagliabuie
Type: TAG 1
Year: 1996
Grinding unit with up drum 1 piece
Band width 1300 mm
Advance system: band
Installed power: 22 kw
7. Evacuation line
Longitudinal conveyor with rollers
Transversal conveyor with belts
Year: 1996
8. Exhaust Spanex
Piping
Filter
Fan debit 11160 cm/hour
Installed power 11kv
Year: 1996
PROFILING LINE NUT- FEDER HOMAG
1. Edge profiling machine HOMAG
Type: FL 10103
Year: 1996
Working heads 6 pieces
Processing width: 150-200mm
Advance system: caterpillar and belt
2. Heads profiling machine HOMAG
Type: FR 20103/25
Year: 1996
Working heads 6 pieces
Processing length: 500-2500mm
Advance system: 2 caterpillars and 2 belts
3. Power system with rollers HOMAG
Type: TR 10/35/04
Year: 1996
4. Evacuation system with rollers HOMAG
Type: TW
Year: 1996
5. Frequency converter Perske
Type: 50DW16-2 ; DA 16-2
Year: 1996
Installed power: 60kw; 28kw
PROFILING LINE CLICK SYSTEM
1. Edge profiling machine IDM
Type: IDM S 29 T4
Year: 1990
Working heads 6 pieces
Processing width: 150-200mm
Advance system: 2 caterpillars and 2 belts
2. Frequency converter MSM
Type: NC 250/750/44
Year: 1990
Installed power: 60kw; 28kw
3. Heads profiling machine HOMAG
Type: FLO 23/26
Year: 1990
Working heads 8 pieces
Processing length: 500-2500mm
Advance system: 2 caterpillars and 2 belts
4. Frequency converter Perske
Type: 35DW16-2 ; DA 16-2
Year: 1990
Installed power: 40kw; 188kw
PROFILING PACKAGING LINE
1. Wrapping machine Kallfass (shrinking foil)
Type: PACK-JET 2000/450
Year: 1996
Installed power: 5kw
2. Wrapping oven Kallfass (shrinking foil)
Type: STANDARD 650N
Year 1996
Installed power: 21kw + 1kw
TOOL DRESSING PARQUET HALL
1. Sharpening circular blades machine Vollmer
Type: UNIMAT S
Year: 1996
2. Sharpening circular blades machine Vollmer
Type: CHC 025
Year: 1996
3. Sharpening circular blades machine Geprufte Sicherheit
Type: VARIO 92-2
Year: 1996
Installed power: 1,0kw
4. Soldering machine for pastille vidia choppers Vollmer
Type: LG 21 H
Year: 1996
5. Deburring machine for pastille vidia Vollmer
Type: CHHF 21H
Year: 1996
COMPRESSORS
1. Compressed-air compressor Atlas Copco
Type: GA 37
Year: 1998
Installed power: 37kw
Max. pressure: 10 bar
Air volume: 82 l/sec.
2. Compressed-air drier Atlas Copco
Type: FD 210 TUV
Year: 1990
Installed power: 1,1 kw
Max. pressure: 13 bar
3. Compressed-air compressor Kaeser
Type: CS 75
Year: 1988
Installed power: 45kw
Max. pressure: 9 bar
Air volume: 5,66 cm/hour.
4. Compressed-air drier Kaeser
Type: T 610 E
Year: 1991
Installed power: 1,2 kw
Maximum pressure: 18 bar
EXHAUST SPANEX
1. Fan
Aspirated volume: 17805 cm/hour
Year: 1996
Installed power: 37 kw
2. Fan
Aspirated volume: 23930 cm/hour
Year: 1996
Installed power: 45 kw
3. Fan
Aspirated volume: 20620 cm/hour
Year: 1996
Installed power: 37 kw
4. Fan
Aspirated volume: 28166 cm/hour
Year 1996
Installed power: 55 kw
5. Fan (evacuation)
Aspired volume: 5250 cm/hour
Year: 1996
Installed power: 18,50 kw
5. Piping
6. Filter
PANELS FACTORY LIST OF EQUIPMENTS
1. Joiner Schroeder
TYPE: PAKE 70
Year: 1996
No. of working trees: 4 pieces
Working dimensions:
- length: 250- 2400 mm
- width: 50- 120 mm
- thickness: 25-50 mm
Ø of tool holder head: 230mm
Installed power -29,1kw
Advance system - chain with spurs
Evacuation system - conveyor with band
2. Finger joint machine Purschke
Type: NKT 99001 ESCHR
Year: 2001
No. of working bands 2buc
Working dimensions:
- lengths: 250- 800 mm
- total width: 600 mm
- thickness: 25-50 mm
3. Profiling machine Weinig 2 buc
Type: U 22 N
Year: 1976
No. of working heads: 7 pieces
4. Machine for applying glue on the edge
5. Press panels with high frequency currents (CIF)
6. Panels formatting circular
Type: NIVESTEIN
Year: 1995
7. Grinding machine DMC
Type: IP 130 PPP
Year: 1995
Grinding unit with low drum 2 pieces
Grinding unit with low probe 1 piece
Grinding unit with up drum 2 pieces
Grinding unit with up probe 1 piece
Band width 1330 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 118 kw
8. Profiling machine Torwegge
Type: EB 288
Year: 1976
No. of working heads: 6 buc
Advance system 2 caterpillars and 2 belts
9. Wrapping machine Beck CO
Type: Packautomaten
Year: 1976
Advance and evacuation system: conveyor with band
10. Wrapping oven Beck CO
Type: Packautomaten
Year: 1976
Advance and evacuation system: conveyor with band
11. Universal carpentry machine FELDER 2 pieces
Type: BF 6_41
Year: 1996
Installed power: 3 kw
12. Air Compressor Atlas Copco
Type: GA 45
Year: 2000
Installed power: 45kw
Maximum pressure: 10 bar
Air volume: 118 l/sec.
13. Hot air dryer Mulbock: 2 pieces
Type: OL 6STB 8,5
Year: 1990
Installed power: 24 kw
Heat agent temperature (hot water): 90˚C
Capacity: 120 cm
14. Hot air dryer Mulbock: 1 piece
Type: ZLSM
Year: 1995
Installed power: 24 kw
Heat agent temperature (hot water): 90˚C
Capacitate: 120 cm
15. Cazan apa calda Mawera
Type: FU 1400 RA
Year: 1989
Work pressure: 4 bar
Work temperature heat agent (hot water): 95˚C
capacity: 4180 cm
16. Exhaust
Fans: 5 pieces
Year: 1989
Piping
Filter
Metallic silo
EQUIPMENT LIST DOORS-WINDOWS FACTORY
1. Processing center Homag
Type: NL 78/PU/S2
Year: 1992
2. Processing center Homag
Type: BOF31 OPTIMAT
Year: 1996
3. Processing center SCM
Type: SUPERSET 23
Year: 1997
4. Processing center SCM
Type: WINDOR 50
Year: 1997
5. Grinding machine MAVEG
Type: SATURN 0
Year: 1989
6. Processing center SCM
Type: FORMAT
Year: 1997
7. Processing center WEEGE
Type: BT 10
Year: 1991
8. Drilling machine
9. Grinding machine
Type: Butfering
Processing unite with up drum and probe
10. Hydraulic press FRIZ
Type: DBT 2342/6
Year: 1969
Working dimensions:
- length: 4200 mm
- width: 2300 mm
- thickness: 150 mm
Heat agent: hot water
11. Mill HOLZ-HER
Type: UF
12. Drilling machine with chain Haffner
Type: SL 100
13. Cold hydraulic press Joos
Turntable 2500x1000
14: Press for timber frames glue Schafberger+Sprodhuber
15. Machine for applying glue on frames Schafberger+Sprodhuber
Type: 9050/0010
Year: 1998
16. Press for glue window frames Hess
Type: LUX UUU DIGITAL
Year: 1997
Installed power 3 kw
17. Grinding machine with horizontal band Langzauner
Type: LZKS
Year: 1986
18. Grinding machine with 4 brushes
Type: UBS
19. Wood lathe Hapro
Type: AP 8000/HF
Year: 1996
Installed power 1,3/2,2 kw
20. Cutting circular Trennjager
Type: UNI 104-6
Year: 1996
21. Plywood Circular Saw Otto Mayer
Type: FSK
Year: 1983
22. Varnishing line in electrostatic field BOLHOF
Type: REITER
Year: 1996
Varnishing cabins 2 lines
Drying: heated oven with hot air (hit agent hot water)
23. Polishing in white table Schuko 2 buc
Type: SATp3
24. Universal carpentry machine Altendorf
25. Chert drill Mayer&Schwabedissen
Tip AZSS 23
26. Universal carpentry machine Wenger
27. Profiling machine Weinig
Type: PHF
Year:1972
No. of working heads: 8 pieces
28. Finger joint machine Grecon
Type: ROT E 150 400 1000
Year: 1996
No. of working bands 1 piece
Working dimensions:
- length : 250- 800 mm
- total width: 600 mm
- thickness: 25-50 mm
29. Mill Otto Martin
Type: T2
Year: 1983
30. Planer machine with mechanical advance REX
Type: HO/D/510
Year: 1963
31. Drilling machine Ayen
Type: ED 084
Year: 1972
Installed power: 0,4kw
32. Universal carpentry machine Martin
Type: T 71
Year: 1982
Installed power: 11kw
33. Optimizing circular with automatic programming (read fluorescent chalk) DIMTER
Type: OKS 400R
Year: 1991
34. Splitting multiple circular Paul
Type: K3U/1500
Year: 1996
Port bushing circular blades L=1500mm
35. Mini saw NEVA
Type TR 88
Year: 1999
Model 150/200
MASSIVE PARQUET LINE
1. Profiling machine Weinig
Type: UNIMAT 22A
Year: 1991
No. of working heads : 7 pieces
2. Profiling machine Torwegge
Type: EB 288
Year: 1976
No. of working heads : 8 pieces
Advance system 2 caterpillars and 2 belts
FINISHING LINE Giardinia
1. Grinding machine ERNST
Type: T 30
Year: 1996
Grinding unite with up probe 2 pieces
Band width 1350 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 75kw
2. Grinding machine VEIT
Type: 223-TM
Year: 1998
Grinding unite with up drum 1 piece
Band width 1300 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 10 kw
3. Dust-brush machine Giardinia
Type: G84-20
Year: 1998
Dust-brush unit with up brush 1 piece
Brush barrel length 1300 mm
Advance system: band
Installed power: 1,5 kw
4. Film drying unit with infrared Giardinia
Type: IRC3
Year: 1998
Installed power: 22,1kw
5. Drench application machine Giardinia (drum)
Type: G95/01
Year: 1998
Max. length 1400 mm
Advance system: conveyor with bars
Installed power: 2 kw
Power system: conveyor with chains with bars
6. Film drying unit with infrared Giardinia
Type: IRC6
Year: 1998
Installed power: 43,7kw
7. Varnish film grinding machine with brushes Giardinia 2 units
Type: G91/30S2
Year: 1998
Max. width 1400 mm
Advance system: conveyor with band
Installed power: 7 kw.
8. Lacquer film drying oven with hot air Giardinia
Type: GP/JET 9
Year: 1998
Max. width 1400 mm
Advance system: conveyor with chain with bars
Installed power: 5,7 kw.
Heat agent: hot water
9. Varnish film grinding machine with brushes Giardinia 2 units
Type: G91/30S2
Year: 1998
Max. width 1400 mm
Advance system: conveyor with band
Installed power: 7 kw.
10. Lacquer application machine Burkle (drum)
Type: SAL 1
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
11. UV lacquer drying system ESEMANN (2 units)
Type: 251
Type: of lamp 2x11,6 kw
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
12. Drench application machine Giardinia (drum)
Type: G95/07
Year: of fabrication 1996
Max. width 1400 mm
Advance system: conveyor with bars
Installed power: 6 kw
Power system: conveyor with chains with bars
13. Film drying unit with infrared Hackemack
Type: IR
Year: 1997
Installed power: 45kw
14. Lacquer application machine Burkle (drum)
Type: SAL 1
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
15. Drying UV lacquer system ESEMANN (2 units)
Type: 251
Type: of lamp 2x11,6 kw
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
16. Varnish film grinding machine ERNST
Type: T 30
Year: 1996
Grinding unit with up prober 1 piece
Band width 1350 mm
Advance system: band
Power system: conveyor with rollers
Installed power: 30kw
17. Lacquer application machine Hymmen (drum)
Type: TLX 1
Year: 1987
Max. width 1300 mm
Advance system: conveyor with bars
18. Lacquer application machine Burkle (drum)
Type: SAL 1
Year: 1996
Max. width 1300 mm
Advance system: conveyor with bars
19. Film drying unit with infrared Giardinia
Type: IRC
Year: 1998
Installed power: 43,7kw
Evacuation system: longitudinal conveyor with rollers
transversal conveyor with belts.
20. Manual pulverization cabins Esemann with water curtain 2 pieces
21. Exhaust
Piping
Filter
Debit fan 10800 cm/hour
Installed power 15,5kv
Year of fabrication 1989
TOOL DRESSING WORKSHOP DOORS-WINDOWS
1. Sharpener for circular canvas made Vollmer
Type: CHC 025
Year: 1996
2. Sharpening machine for canvas at mini frame saw Weinig
Type: R 934
Year: 1996
3. Sharpener for circular canvas Vollmer
Type: UW S71U
Year: 1995
4. Sharpener for flat knives Weinig
Type: R 45
Year: 1996
4. Soldering machine for pastille vidia Vollmer
Type: LG 21 H
Year: 1996
5. Deburring machine pastille vidia Vollmer
Type: CHHF 21H
Year: 1996
COMPRESSORS
1. Compressed-air compressor Kaeser
Type: CS 90
Year: 1992
Installed power: 55kw
Maximum pressure: 10 bar
Air volume: 7,84 cm/hour.
4. Compressed-air drier Kaeser
Type: MDT-H 380E
Year: 1986
Installed power : 1,2 kw
Maximum pressure: 18 bar
EXHAUST SCHUKO year 1992
1. Fan SCHUKO K 400 =3 pieces
Aspirated volume: 12660 cm/hour
Year: 1992
Installed power : 15 kw
2. Fan SCHUKO K 500
Aspirated volume: 17400 cm/hour
Year: 1992
Installed power : 22 kw
3. Fan SCHUKO (evacuation)
Aspired volume: 7120 cm/hour
Year: 1992
Installed power : 7,5 kw
4. Piping
5. Filter
EXHAUST WEBER
1. Fan Weber 6.5 =3 pieces
Aspired volume: 29160 cm/hour
Year: 1979
Installed power : 37 kw
2. Fan Hering
Aspired volume: 13600 cm/hour
Type: MEBT 400 R 90
Installed power : 25 kw
3. Fan Weber 3.5 (evacuation)
Aspired volume: 8750 cm/hour
Year: 1982
Installed power : 10 kw
4. Filter Weber
5. Piping

Note:
The specifications and descriptions are a copy of the order confirmation at that time. Data are for information and are not binding.


weitere Videos:
<a href="https://youtu.be/ZdzyYcaxGgk">https://youtu.be/ZdzyYcaxGgk</a>
<a href="https://youtu.be/WA2BvAjwA5g">https://youtu.be/WA2BvAjwA5g</a>
<a href="https://youtu.be/ARYJfQUrxf8">https://youtu.be/ARYJfQUrxf8</a>
<a href="https://youtu.be/-2xMmqsVbYg">https://youtu.be/-2xMmqsVbYg</a>

Ansprechpartner

Klaus-Dieter Büscher
Vertrieb Norddeutschland & BeNeLux
Ralf Teubner
Vertrieb Südwestdeutschland & Export
